ARES RALLY
BatteryCapacity:35Ah / 2590Wh
Cells:LG Premium 21700 lithium cells
Features:Removable, can be charged when installed in bike or separately.
Voltage (nominal):74V
Brake modesBrake mode
1:Motor brake with energy regenerationBrake mode
2:Freewheel, no motor brake
BrakesDisc:Suspension disk, 210mm diameter, 2.3mm thicknessType:Disc brakes, Four piston calipers, alloy levers. Hand lever for front- and rear brake.
Charging0-:3 hours0-80%:2 hoursType:Variable voltage External charger for 100V-240V outlets :Best-in-class power density and state-of-the-art motor control algorithms.MeterLED instrument panel
DrivetrainChain:420 chain with DXElectric motor:Internal Rotor Permanent Magnet Synchronous MotorFront sprocket:11 teethNominal power:5 kWPeak power:12.5 kW**Rear sprocket:58 teethTorque (motor axle):58 N·mTorque (wheel):305 N·mType:Direct drive, chain
DimensionsFork angle:24°Ground clearence:280mm - 11.43''Offset:15mm in triple clamps, 45mm in forksSeat height:815mm - 33.26''Trail:111mm - 4.37''Wheel base:1330mm - 52.36''
Fenders & BodyworkMaterial:PP/ABS plastic
FrameBuild:6082 aluminium - extruded, forged and CNC machinedSeat cushionRed, Integrated foaming process
Front suspensionTravel:200mmType:Upside-down air forks featuring 45mm stanchion tubes for extra rigidity and strength, Double shoulder adjustable front damper.
HandlebarMaterial:6061 aluminiumRise:22mmWidth:760mm
Rear suspensionTravel:75mmType:240mm shock ,Compression damping / rebound damping adjustable + Spring preload adjustable.
:off-roadLicense:CE / FCC
